Fluidyne 616/617 Series Bar Plate Engine Oil Coolers 14.75 Inches x 9.25 Inches x 3 Inches
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Fluidyne – Where Performance Meets Precision in Oil Cooling!
When the heat is on, only the best will do, and that’s where Fluidyne steps into the spotlight. Elevate your cooling game with our cutting-edge bar and plate coolers, meticulously crafted through countless hours of research and development. These aren’t just coolers; they’re champions born from the demanding tests of both wind tunnels and race tracks.
Fluidyne oil coolers stand tall as the victors of thousands of races over the last 30 years, earning the trust of the best in the business.
Why settle for anything less when you can experience the winning edge with Fluidyne?
Dive into a world of superior engineering, where each cooler boasts optimal heat transfer characteristics. Our exclusive fin design, coupled with a densely packed structure, ensures that your oil enjoys the coolest temperatures possible while maintaining minimal pressure loss. Picture this – a design so advanced, it’s like having a high-performance orchestra playing for your engine!
But that’s not all. Our bar and plate coolers go through a state-of-the-art process, being brazed in a vacuum furnace. What does that mean for you? Zero leaks and the most robust bond conceivable between the tube and heatsink. We’ve engineered these coolers to perfection, ensuring a seamless performance that stands the test of time.
Mounting your cooler has never been easier, thanks to the thoughtful design featuring four holes on the flanges. Fluidyne doesn’t just provide cooling; it’s an experience, a statement, and a commitment to excellence. When performance matters, make the bold choice – Fluidyne, where innovation meets victory!
We offer multiple sizes of bar and plate coolers. Please see the table below for sizes and design information to get the perfect one for your application.
Oil Cooler Type : 30616 Series Oil Cooler 14.75 Inches x 9.25 x 3 Inches \, ½ Inches NPT and 12AN fittings Single Pass, 30617 Series Oil Cooler 14.75 Inches x 9.25 x 3 Inches \, ½ Inches NPT and 12AN fittings Dual Pass
| SKU | OGEN.DB-30616 | OGEN.DB-30617 |
| Overall Dimensions | 14.75″ L X 11.61″ H X 3.25″ D | 14.75″ L X 11.61″ H X 3.25″ D |
| Length | 14.75″ | 14.75″ |
| Height | 11.61″ | 11.61″ |
| Depth | 3.25″ | 3.25″ |
| Weight | NA | NA |
| Core Length | 12.25″ | 12.25″ |
| Core Height | 9.25″ | 9.25″ |
| Core Depth | 3″ | 3″ |
| Core Dimensions | 12.25″ L X 9.25″ H X 3″ D | 12.25″ L X 9.25″ H X 3″ D |
| Overall Length Range (in.) | 14.00-14.99 | 14.00-14.99 |
| Overall Height Range (in.) | 11.00-11.99 | 11.00-11.99 |
| Fluid Cooler Type | Universal | Universal |
| Fluid Cooler Inlet Size | 1/2″ NPT, -10AN Oring | -10 AN O-ring |
| Fluid Cooler Outlet Size | 1/2″ NPT, -10AN Oring | -10 AN O-ring |
| Inlet Attachment | Female O-ring | Female O-ring |
| Outlet Attachment | Female O-ring | Female O-ring |
| Number Of Passes | Single Pass | Dual Pass |
| Number of Cooling Rows | 29 | 29 |
| Cooler Construction | Bar Plate | Bar Plate |
| Cooler Material | Aluminum | Aluminum |
| Cooler Color | Silver powdercoated | Silver powdercoated |
| Fan Included (TRUE/FALSE) | FALSE | FALSE |
| Fan Quantity | NA | NA |
| Fan Diameter | NA | NA |
| Fan CFM Range | NA | NA |
| Maximum Fan CFM | NA | NA |
| Universal (TRUE/FALSE) | TRUE | TRUE |
| Notes | NA | Includes two -10ORB to 12AN Custom Fittings with 12AN Diameter Internal. Great for oil, transmission and supercharger heat exchangers |
| Length | 14.75" |
|---|---|
| Height | 9.25" |
| Depth | 3" |
